3PC Flanged Ball Valve With F.R.L Unit
3PC Flanged Ball Valve With F.R.L Unit
Specification
Size
1/2"~6"
Material
SS304/SS316/WCB
Pressure
150LB/300LB
Temperature
-20~150 degree(PTFE)
-20~180 degree(RPTFE)
-20~280 degr
3PC Flanged Ball Valve With F.R.L Unit
Specification
| Size | 1/2"~6" |
| Material | SS304/SS316/WCB |
| Pressure | 150LB/300LB |
| Temperature | -20~150 degree(PTFE) |
| -20~180 degree(RPTFE) | |
| -20~280 degree(PPL) | |
| Medium | W.O.G and some Corrosive Liquid |
| MOQ | 10 PCS |
| Certificate | ISO9001:2008/CE |
Product Description
- Investment casting steel body
- Blow-out proof stem
- Full bore
- Anti-static device on ball and body
- ISO 5211 direct mounting pad for actuator
- Locking handle device option
- Pure TEFLON seals and seats
- 100% leakage tested at 100 psi aire under water
Standard
- Design Acc: ASME B16.34 & API 6D
- Fire-safe Design: API607
- Face to Face Dimension: ASME B16.5
- Flange connection Acc: ASME B16.10
- Wall thickness: ASME B16.34 EN12516-1
- Inspection&Testing Acc: API598
